    Rigid Stranding Machine With Auto Loading Device Which Is From 6B 12B 18B 30B 37B 54B 61B

    Ask Lasest Price
    Brand Name : Beyde
    Model Number : 630/12+18+24+30+36
    Certification : CE
    Payment Terms : D/A, D/P, T/T, L/C
    Supply Ability : 200 set/year
    Delivery Time : 90 days
    • Product Details
    • Company Profile

    Rigid Stranding Machine With Auto Loading Device Which Is From 6B 12B 18B 30B 37B 54B 61B

    Rigid Stranding Machine With Auto Loading Device Which Is From 6B 12B 18B 30B 37B 54B 61B



    This machine mainly used for aluminum,copper and ACSR shaped or round conductor stranding,compacting, drawing and single-core preforming processing.


    Component:
    Central pay off, stranding cage, assemble holder,compact holder, traction device, take-up and traverse device, electrical control system, and transmission system.


    Primary highlights:

    • Self supporting unbending rotor outline with 36, 30, 24, 18, 12, 6 and 1 bobbin cage
    • High proficiency and speed
    • Bobbins attached on pintles
    • Line directed by A.C. or, then again D.C. engines with automatic or electric synchronization among line parts.
    • Diverse braking gadget for bobbins
    • Centralized greasing framework for bearing
    • Circle sort Pneumatic brake for enclosure
    • Machines sans or with back twist
    • Can be equipped with MMI/PLC that is discretionary
    • Simple Lay configuration
    Model (Rigid Stranding Machine)JLK-500JLK-630JLK-710/720
    Diameter of single wireCopperφ1.5-5 mmφ1.5-5 mm φ1.5-5 mm
    Aluminumφ1.5-5 mmφ1.5-5 mmφ1.5-5 mm
    Maximum stranded conductor ODφ35-55 mmφ35-55 mmφ35-55 mm
    Stranding Pitch6 Bobbin Stranding Cage40-719 mm51-896 mm54-963 mm
    12 Bobbin Stranding Cage40-719 mm51-896 mm54-963 mm
    18 Bobbin Stranding Cage44-793 mm63-1056 mm57-1012 mm
    24 Bobbin Stranding Cage51-924 mm71-1246 mm66-1190 mm
    30 Bobbin Stranding Cage57-1028 mm87-1553 mm79-1403 mm
    Rotating Speed6 Bobbin Stranding Cage230.6 r/min180.1 r/min150.6 r/min
    12 Bobbin Stranding Cage230.6 r/min180.1 r/min150.6 r/min
    18 Bobbin Stranding Cage208.5 r/min155 r/min142.6 r/min
    24 Bobbin Stranding Cage179 r/min130.1 r/min122.3 r/min
    30 Bobbin Stranding Cage161.8 r/min115.9 r/min102.7 r/min
    CapstanCapstan Wheel Diameter2000 mm2000 mm2000 mm
    Maximum Haul-off Force30 T30 T40 T
    Pre-spiral DevicePitch500-2500mm500-2500mm500-2500mm
    Motor Power90-180 KW110-180 KW130-180 KW
    Bobbin Size500*375*127630*475*127710*530*127
    Center Payoff Bobbin1600*800*801600*800*801600*800*80
    Take-up Bobbin2500*1500*1252500*1500*1253150*1900*160
    Maximum Haul-off Linear Speed69 m/min69 m/min62 m/min
    Central Height1000 mm1100 mm1100 mm


    Company strength

    Located in Hejian, Hebei province, BEYDE Co., Ltd is recoganized from Hejian Hongqi Machinery Inc. Since established in 1983, we put all our efforts to design, produce, sale and serve for our customer. Our main products including Rigid Stranding machine, Tubular Stranding machine, Planetary Stranding machine, Bow Stranding machine, Laying-up machine, Drum Twister, Armouring machine and so on. Our products are widely used all over the world, and our brand "Hongqi machine" become famous in China.Now we are proudly of well-known brand and becoming the leading team in this field.
